Product Characteristics
1.Strong Angular Compensation
It can transmit power at different angles and shaft misalignment, allow large installation deviation, suitable for offset installation conditions.
2.High Transmission Efficiency & High Torque
Low power loss, high load torque and stable operation, ideal for heavy industry, mining and high-power transmission equipment.
3.Telescopic & Adjustable Length
Some models are telescopic, able to compensate axial distance error, easy for installation and adjustment.
4.Shock Absorption & Impact Resistance
Good buffering performance to absorb startup and shutdown impact, protect motor and reducer.
5.Simple Structure & Easy Maintenance
Compact structure with high strength and long service life, no complicated daily maintenance required.
6.Wide Application
Widely used in engineering machinery, metallurgy, mining, paper making, conveyor equipment and agricultural machinery.
Material Introduction
1.45# Carbon Steel
Most common material, high strength, good toughness, wear resistance and anti-deformation, cost-effective for general industrial use.
2.Alloy Steel
Quenched and tempered for higher hardness and super high torque capacity, suitable for heavy-duty and high-load machinery.
3.304/316 Stainless Steel
Rust-proof, acid and alkali corrosion resistant, suitable for food, medical, chemical and humid outdoor environments, applied for light and medium load.
4.Cast Iron
Low cost with good shock absorption and stability, mostly used for low-speed and low-torque general transmission.
FAQ:
It is mainly caused by worn serpentine springs, aging and fatigue of elastic parts, excessive coaxiality deviation during installation, excessive clearance of shaft holes at both ends, and loose fixing bolts. Recalibrate the coaxiality, replace the serpentine springs and aging elastic parts, and tighten the bolts to solve the problem.
Q：Is the KS coupling high temperature resistant? What is its applicable temperature range?
Conventional cast iron and steel KS couplings with standard elastic parts are suitable for temperatures from -20℃ to +80℃. High-temperature resistant springs and sealing parts can be customized for high working temperature conditions.
Q：Can KS coupling be customized in non-standard sizes?
Non-standard customization of outer diameter, shaft hole diameter, length and keyway specification is supported. We can process and produce according to drawings and equipment dimensions.
